Scienta 9144 – fixed point scanner
Key Features
- Fixed Point Scanner Model with C-frame sensor support
- Measurement position 400 mm from sheet edge
- Scanning of sheet edge to show edge moisture profile
- Tolerates sheet fluctuations
- All stainless steel construction for narrow space installations
- External PLC cabinet with touch panel local display
- Connection to DCS with Profinet, Modbus, OPC or analog signals
Installation Examples
Features
- Model 9144 for C-frame installation
- Model 9144P for single-sided installation
- Stainless Steel construction
- Adjustable reach, max. 500 mm (9144P up to 3 m)
- Service free construction
- Easy and convenient to install and operate
- Works well in dirty and humid conditions
- Data analysis (FFT etc) add-on program available
Technical Specifications
| Scanner Type | 9144 |
| Construction | Double-sided, C-frame, Stainless Steel construction |
| Max Measuring depth | 400 mm |
| Extras | Guide rolls for the sheet |
| Power supply | 24 VDC, 5A |
| Electric Cabinet | Rittal AE1038 380x600x210 mm |
| Head cooling | Air cooling of sensor electronics |
| PLC | Siemens S7-1200 |
| Scanner Type | 9144P |
| Construction | Single-sided, Stainless Steel construction Timing belt drive |
| Max Measuring depth | 3000 mm |
| Extras | Guide rolls for the sheet |
| Power supply | 24 VDC, 5A |
| Electric Cabinet | Rittal AE1038 380x600x210 mm |
| Head cooling | Air cooling of sensor electronics |
| PLC | Siemens S7-1200 |
